    SUS316L Horizontal Milk Transport Tank With Insulation Layer 1000L-8000L Capacity

    Ask Lasest Price
    Brand Name : Shanghai Beyond
    Model Number : BY-MTOT
    Certification : SGS/CE/ISO9001
    Price : negotiation
    Supply Ability : 50 pcs per month
    Delivery Time : 35-50 working days upon receipt of payment and confirmed the drawings
    • Product Details
    • Company Profile

    SUS316L Horizontal Milk Transport Tank With Insulation Layer 1000L-8000L Capacity

    milk tanker/milk trasnporting tank/ milk storage tank/horizontal milk transportation tank


    The milk tanker is widely used for long distance transportation of milk or other liquid products. The tank wall adopts high quality SUS304-2B stainless steel , the jacket adopts high density PU as insulation with new procedure, all the radius of inner corners b are made as big circular arc transition to avoid sanitary dead angel; and CIP spraying balls are fixed inside which enables the easy cleaning. It meets industry standard and food sanitary requirements.

    The tank can keep the milk in good quality during the transportation, improve the sanitary conditions, reduce transfer cost and save labor. It can be as s truck when it does not transfer liquid milk, and download the tank.


    Technical Parameter:

    Tank volume1000L, 2000L, 3000L, 4000L, 5000L, 6000L, 8000L, 10000L, 12000L, 15000L, 20000L
    Temperature-20℃~+40℃, liquid temperature:4+/-1°, temperature difference ≤ 2℃.
    Standard configuration

    Quick-opening sealed manhole, breathing valve, CIP cleaning pipes, material inlet (with valve)

    MaterialSUS 304, Food hygiene grade silicone ring for seal
    DimensionAccording to the size of truck chassis provided by customer

    1. Small scale pasteurizer plant

    These small scale pasteurizer plant need to have basic units and components that the supplier need to like


    • Milk receiving tank,
    • Pasteurizer unit,
    • Chiller unit and
    • Filling and Packing units
    • list of accessories (valves, fittings, cables and wiring, panel board, flanges, tools, filter, packing film sterilizer, two way clean in place system, pumps, pipes, cold room, rapid microbial testing equipment, control systems, safety system for the boiler etc)

    Utilities (compressor, boiler (preferably the electrical one with heat recovery system efficiency


    Equipment list necessary for 20T/day milk processing (new plant)


    1. Measuring scale for receiving milk from trucks and weighing it (10,000L/h)
    2. Cleaning system for cleaning milk transporting trucks
    3. Milk purifier (5000L/h)
    4. Plate heat exchanger (5000L/h)
    5. Heat protected tank for milk (4pcs 5000L, 2pcs for the beginning)
    6. Milk pump 2pcs (10000L/h)
    7. Equipment for milk pasteurization and cooling (5000L/h)
    8. Cream separator, purifier (5000L/h)
    9. Equipment for milk cream pasteurization and cooling (1000L/h)
    10. Screw pump for cream (2000L/h)
    11. Tank for cream aging (fermentation) and keeping (600L)
    12. Tank for normalizing milk parameters, 2pcs (1000L)
    13. Tank for normalizing matzoun (a product similar to yogurt) 2pcs (1000L)
    14. Curds cooking tank (1000L)
    15. Curds packing machine
    16. Milk and sour-cream homogenizer (1000L/h)
    17. Tank for yogurt and products similar to yogurt (600L)
    18. Water sucking vacuum pump for matzoun
    19. Packing machine for filling milk in PurePak containers (1000L/h)
    20. Machine for filling matzoun in PS cups (1000L/h)
    21. Machine for filling and sealing sour-cream and yogurt into 100g., 200g. and 500g. cups (2000L/h)
    22. Cheese vat 2pcs (1000L)
    23. Cheese (Chanakh, Lori) moulds, tables, press and other
    24. Cream separator
    25. Cream collecting tank (1000L)
    26. Cream keeping tank (300L)
    27. Refrigerator for keeping milk products (30m2)
    28. Chamber for matzoun keeping (10m2)
    29. Butter making machine (250kg/h)
    30. Vacuum packing machine for cheese
