    2000LPH/3000LPH/5000LPH/8000LPH low sugar tea drink Extracting tank/ herbal tea extraction system

    Ask Lasest Price
    Brand Name : BEYOND
    Model Number : BY-5000LPH
    Certification : ISO9001
    Price : USD220000-680000USD
    Payment Terms : L/C, T/T
    Supply Ability : 60sets per year
    Delivery Time : 50-80days
    • Product Details
    • Company Profile

    2000LPH/3000LPH/5000LPH/8000LPH low sugar tea drink Extracting tank/ herbal tea extraction system

    2000LPH/3000LPH/5000LPH/8000LPH low sugar tea drink Extracting tank/ herbal tea extraction system


    Extracting tank

    This extracting tank is mainly used to extract tea from the tea leaves, or make medicine from herbal medicine.


    All the tank wall is made of high quality SUS304-2B stainless steel, the jacket adopts high density of PU as insulation; this tank can use steam to heat the product inside with steam or hot water inside of the dimple pad; the paddle type agitator is mounted from top at the centre; other standard attachments such as: airtight manhole, high and low level probe, temperature sensor.


    The extracted liquid product is discharged from bottom outlet; dregs are also discharged from bottom where a net is fixed to separate the dreg from the liquid product; the top cover is elliptical type and bottom base is of conical types.

    Technical Parameter

    ModelDiameterExternal diameter

    Height

    (mm)

    Insulation(mm)

    Jacket

    (mm)

    Diameter of inlet/outlet
    BYCQ-5005008002140501.5φ38/φ51
    BYCQ-1100010502380501.5φ38/φ51
    BYCQ-1.5150011802550501.5φ38/φ51
    BYCQ-2200013402760501.5φ38/φ51
    BYCQ-2.5250014202940501.5φ38/φ51
    BYCQ-3300015403050501.5φ38/φ51
    BYCQ-4400016503200501.5φ38/φ51
    BYCQ-5500017803250501.5φ38/φ51

    Brand Name:Shanghai Beyond
    Model Number:BY-ETJ
    Capacity3000-20000BPH
    Raw materialVitamins ,Various fruit juice, juice concentrate, tea leaf, tea powder, cereal, health care ingredients
    End productEnergy drink, fruit juice, tea beverage, functional beverage
    Shelf life180-365days
    Final product packagePET bottle, aluminium cans, tin cans, standup pouch etc. Pre-pak pouch, Brik carton, plastic bag, Gable top bag, Plastic cup, glass bottle, etc.
    Filling volume200ml, 350ml, 450ml, 500ml, 1L, 1.5L etc
    Main material for machinesSUS304 or SUS316
    Certification:ISO9001/CE/SGS
    Place of Origin:China
    Manufacturer historyMore than 10years

    2000LPH/3000LPH/5000LPH/8000LPH low sugar tea drink Extracting tank/ herbal tea extraction system2000LPH/3000LPH/5000LPH/8000LPH low sugar tea drink Extracting tank/ herbal tea extraction system


    2000LPH/3000LPH/5000LPH/8000LPH low sugar tea drink Extracting tank/ herbal tea extraction system2000LPH/3000LPH/5000LPH/8000LPH low sugar tea drink Extracting tank/ herbal tea extraction system


    Product Name3000-20000BPH energy drink and tea beverage line
    Processing line typeComplete turn-key project
    Power consumption(Kw)energy saving type, about 100-500kw,
    Operator neededAbout 4-18persons
    Cooling water consumptionAbout 60-500M3
    Steam consumptionAbout 200-4000T/H,
    Factory space neededAbout 400-6000Sqm
    Warranty12 months
