    SUS304 SUS316L Fruit Clapboard Elevator Fruit Processing Equipment For Fruit Conveying

    Ask Lasest Price
    Brand Name : beyond
    Model Number : BY-C
    Certification : CE/ISO9001
    Price : negotiation
    Supply Ability : 50 pcs per month
    Delivery Time : 35-60 working days
    • Product Details
    • Company Profile

    SUS304 SUS316L Fruit Clapboard Elevator Fruit Processing Equipment For Fruit Conveying

    Shanghai Beyond Machinery Co., Ltd. is a professional machinery manufacturer based on technical developing. Combining with R&D, manufacturing, installation debugging and training, we are engaged in producing the liquid projects used in Dairy,Fruit &Vegetable juice,Beverage,Tea,Brewing,Flavoring,Pharmacy,Egg,Bone & Meat processing and Daily chemical products etc.


    Fruit elevator plastic clapboard elevator fruit conveying machine


    Introduction

    Clapboard elevator transports the product by moving the clapboard driven by the motor.

    Construction Type: horizontal and gradient;

    Material of the clapboard: Supporter is made of SUS304-2B stainless steel; the clapboard is made of stainless steel or plastic PP (polypropylene), which is applicable for all kinds of fruits and vegetables.

    Fruits can be feed or discharged into the lifter at any points of the machine.


    Technical parameter

    ModelDescription

    Transportation capacity

    (based on Apple)

    Motor power (kw)
    Line speedCapacity
    GBTS-S400

    The supporter is made of SUS304 stainless steel,

    the clapboard is made of SUS 304 or plastic;

    moving speed is adjustable

    0.1-0.4m/s2.5-4(m³/H)2-5m0.55
    6-10m0.75
    GBTS-S6000.1-0.4 m/s4-6(m³/H)2-5m1.1
    6-10m1.5
    GBTS-S8000.1-0.4 m/s6-8(m³/H)2-5m1.5
    6-10m2.2
    GBTS-S10000.1-0.40 m/s8-10(m³/H)2-5m1.5
    6-10m2.2
    GBTS-S12000.1-0.4 m/s10-15(m³/H)2-5m1.5
    6-10m3
    GBTS-S14000.1-0.4 m/s15-20(m³/H)2-5m2.2
    6-10m4


    Technical Parameter:


    NameDescriptionTransportation capacity(kw)
    Power
    line speedCapacity
    GBTS-S400the supporter is made
    of SUS304 stainless steel,
    the clapboard is
    other SUS304 stainless
    steel or plastic,
    speed is adjustable
    0.1-0.4m/s2.5-4m3/H2-5m0.55
    6-10m0.75
    GBTS-S6000.1-0.4m/s4-6m3/H2-5m1.1
    6-10m1.5
    GBTS-S8000.1-0.4m/s6-8m3/H2-5m1.5
    6-10m2.2
    GBTS-S10000.1-0.4m/s8-10m3/H2-5m1.5
    6-10m2.2
    GBTS-S12000.1-0.4m/s10-15m3/H2-5m1.5
    6-10m3
    GBTS-S14000.1-0.4m/s15-20m3/H2-5m2.2
    6-10m4
