    Forced Circulation Multiple Effect Evaporator With SUS304 / SUS316 Stainless Steel Material

    Multiple Characteristics Four Effect Evaporator with Variable Using Scope


    Introduction

    This equipment adopts four effects falling film to evaporate the water in the milk or fruit juice;

    Construction: evaporator,separator,condenser etc.

    Usage: popularly used for concentrating and dehydration in food,biology engineering,pharmacy and chemistry etc.

    Automatic control: manual operated and full auto control;


    Technical parameter(calculated based on water evaporating))

    ModelEvaporation capacity of water

    External dimension

    (L×W×H)(mm)

    Steam consumption

    (kg/h)

    Suggested power(kw)
    JNS-4-5≤5(T/H)8000*4000*11000≤1.5(T/H)36
    JNS-4-8≤8(T/H)9000*4500*11000≤2.4(T/H)48
    JNS-4-10≤10(T/H)10000*4500*11000≤3(T/H)55
    JNS-4-15≤15(T/H)12000*5000*11000≤4.5(T/H)80
    JNS-4-20≤20(T/H)13500*5000*11000≤6(T/H)105
    JNS-4-30≤30(T/H)16000*6000*11000≤9(T/H)145

    Characteristics

    1. Adopts four effect type, high utilization ratio of steam, low energy consumption;

    2. Full closed process, fast and low temperature evaporation; so the nature color and flavor and smell is well remained.

    3. High heat transfer efficiency and material flow speed,and strong fouling resistance;

    4. Large scale of the concentrate ratio——as the products between the different effects can recycle separately, the concentrate ratio can be regulated in large scale;

    5. The machine attach with spraying ball and self CIP system with closed balance tank and acid/alkali tank, by which to avoid contamination and the volatilization of acid/alkali.
