    Large Outdoor Stainless Steel Storage Tanks / SUS304 SUS316 Stainless Steel Dairy Equipment

    Ask Lasest Price
    Brand Name : Shanghai Beyond
    Model Number : BY-LOST
    Certification : SGS/CE/ISO9001
    Price : negotiation
    Supply Ability : 50 pcs per month
    Delivery Time : 35-50 working days upon receipt of payment and confirmed the drawings
    • Product Details
    • Company Profile

    Large Outdoor Stainless Steel Storage Tanks / SUS304 SUS316 Stainless Steel Dairy Equipment

    Stainless steel large outdoor milk storage tank SUS304 SUS316

    Usage: Applicable for large milk collection center, or for milk outdoor storage at large milk production plant; also used at other food and pharmacy factory for storage of liquid product.This equipment is equipped with cleaning system, agitator, sight and view devices, also have attachments of thermometer and level indication meter.

    Specifications:

    ★Material: all material used is high quality sus304-2B stainless steel or SUS 316, inner shell δ=3-4mm and out shell δ=2mm and cooling jacket δ=1.5mm;

    ★Structure: cylindrical shape, conical top cover of 15 degree, with skirt base; with PU(Polyurethane) as heat insulation; with cooling dimple pad at tank wall and base.

    ★Volume range: 15,000L-120,000L

    ★ Standard configuration:

    a). One air tight side manhole;

    b). One side mounted agitator at the bottom;

    c). One PT100 thermometer, temperature range 0~100℃;

    d). Two CIP cleaning balls;

    e). One aseptic sample valve;

    f). Anti butterfly and dirt air vent;

    g). Product inlet/outlet;

    h). Cooling medium inlet/outlet;

    i). Level sensor;

    j). Ladder with circle protection and protection fence at tank top

    Technical parameter:

    ModelEffective volume(L)External diameter(mm)Total height(mm)Heat insulation layer(mm)Diameter of inlet/outlet

    Motor

    Power (kw)

    Side agitator speed(rpm)
    BYCG-151500022006500100φ515.5960rpm
    BYCG-202000023807150100φ515.5960rpm
    BYCG-303000027007850100φ515.5960rpm
    BYCG-505000032009200100φ515.5960rpm
    BYCG-606000034009800100φ515.5960rpm
    BYCG-100100000362012990100φ515.5×2960rpm
    BYCG-120120000370014200100φ515.5×2960rpm

    Other volumes not specified, we could customize as to customers’ requirement.

    And we will recommend manufacturing on site for the volumes that more than 120T.


    Applicable for large milk collection centre, or for milk outdoor storage at large milk production plant; also used at other food and pharmacy factory for storage of liquid product. This equipment is equipped with cleaning system, agitator, sight and view devices, also have attachments of thermometer and level indication meter.
    Material: all material used is high quality SUS304-2B or SUS316L stainless steel, inner shellδ=3-4mm and out shellδ=2mm and cooling jacket δ=1.5mm;

    Structure: cylindrical shape, conical top cover of 15 degree, with skirt base; with PU(Polyurethane) as heat insulation; with cooling dimple pad at tank wall
    and base.

    Volume range: 15,000L-120,000L

    Standard attachments:
    a) One air tight side manway;
    b) One side mounted agitator;
    c) One PT100 thermometer, temperarure range 0~100 degc;
    d) Two cip cleaning ball;
    e) One aseptic sample valve;
    f) Anti butterfly and dirt air vent;
    g) Product inlet/outlet;
    h) Cooling medium inlet/outlet;
    i) Level sensor;
    j) Ladder with circle protection and protection fence at tank top.
