    1000L - 10000L Cleaning In Place System , Cip Systems Dairy Industry With 4 Tank Double Circuits

    Ask Lasest Price
    Brand Name : BEYOND
    Model Number : BY-CIP
    Certification : ISO 9001/SGS/CE
    Price : USD 24100-USD82000
    Supply Ability : 60sets per year
    Delivery Time : 50-70working dyas
    • Product Details
    • Company Profile

    1000L - 10000L Cleaning In Place System , Cip Systems Dairy Industry With 4 Tank Double Circuits

    1000L-10000L CIP cleaning system with 4 tanks double circuits for Juice line, beverage processing plant


    Split type full-auto CIP cleaning system

    The operating principle of the full auto CIP cleaning system refers that the tank body, pipelines, pumps and all valves and also the whole processing line are cleaned on line no need to disconnect the pipes or the equipments, all cleanings are done at the closed circuit.

    1000L - 10000L Cleaning In Place System , Cip Systems Dairy Industry With 4 Tank Double Circuits


    Configuration table

    ItemBrand or supplier
    ControllerSiemens PLC, color screen, full automatic control
    Conductivity meterGermany JUMO
    Flow switchGermany IFM
    Pneumatic valveGermany GEA
    Concentrated acid/alkali adding systemUSA sandipipe diaphragm pump
    Level alarmat high/low level
    Steam pressure reducer valveSpirax Sarco from UK
    Temperature regulating systemSpirax Sarco from UK
    Temperature sensorGermany JOMO
    Electromagnetic flow meterGermany E+H
    Frequency converterDanfoss
    Tank thicknessInner shell of CIP tank is 3mm;Outer cladding is 1.5mm
    PU insulation, heating by plate heat exchanger, separately standing tanks, material SUS304, in acid/alkali tank with vertical agitator, flow rate 10-20m³/h, pump head 24 meters, stainless steel control box.

    Main components list

    Itemparts
    CIP cleaning liquid storage tanksInclude acid tank, alkali tank, hot water tank, clear water tank
    Concentrated acid and alkalisingle layer storage tank for each
    PumpsCIP forward and return pumps
    Two diaphragm pumps for acid/alkali concentrate
    Heat exchangerPlate or tubular type
    Control cabinetOne electrical appliance box
    Pipes and valvesOne set of controlling pipe and valve component
    Electrical appliance materialOne set of auto-performance components and parts and the electrical appliance material.
    CIP cleaning liquid storage tank1000L-10000L.
    Cleaning recyclesSingle circuit, double circuits, three circuits ,four circuits or multi circuit operating at the same time; We can customized as to customers’ need
    Heating typePlate type, coil tube type, tubular type.

    1000L - 10000L Cleaning In Place System , Cip Systems Dairy Industry With 4 Tank Double Circuits

    Company introduction

    Shanghai Beyond Machinery Co., Ltd, as a private business started in the year of 2005, is a specialized technology-oriented machinery manufacturing enterprise. Integrating scientific research and development, production, installation, commissioning and training, Beyond specializes in the turn-key projects of the design, manufacture, installation and commissioning for the production lines of liquid food such as dairy, drink, ice cream, fruit and vegetable, bioengineering, chemical and pharmaceutical. Through the years of the common efforts of our staff, we have obtained high share in the market of machinery industry, and have developed ourselves into a medium-sized enterprise of certain popularity in the industry. Combining scientific research, technical development, production, marketing and after-sale service, we keep ourselves acting strictly in accordance with the quality assurance system of ISO9001. Supported by a team of highly qualified design, production, marketing and after-sale service people, we have formed up distinctive corporate culture and operation philosophy, and a united, diligent and upward team.
