    Industrial 1000l Ice Cream Making Machine For Ice Cream Processing Line

    Ask Lasest Price
    Brand Name : Beyond
    Model Number : BYNNX
    Certification : CE certificate/ISO9001/SGS
    Price : negotiable
    Supply Ability : 20 pcs per month
    Delivery Time : 90-120 days
    • Product Details
    • Company Profile

    Industrial 1000l Ice Cream Making Machine For Ice Cream Processing Line

    ice cream processing line 1000L ice cream production line ice cream aging tanks with 200ml cup packing

    Figure shows ice cream ice cream processing equipment:
    1. Ice cream mix preparation module containing
    2. Water heater
    3. Mixing and processing tank
    4. Homogeniser
    5. Plate heat exchanger
    6. Control panel
    7. Cooling water unit
    8. Ageing tanks
    9. Discharge pumps
    10. Continuous freezers
    11. Ripple pump
    12. Filler
    13. Manual Can filler,
    14. Wash unit

    DESCRIPTION
    -Formulation:
    The ingredients used in ice cream production are: fat;milk solids-non-fat (MSNF);sugar/non-sugar sweetener;emulsifiers/stabilisers;flavouring agents;colouring agents.

    -Weighing, measuring and mixing:
    Generally speaking, all dry ingredients are weighed, whereas liquid ingredients can be either weighed or proportioned by volumetric meters.

    -Homogenisation and pasteurisation:
    The ice cream mix flows through a filter to a balance tank and is pumped from there to a plate heat exchanger where it is preheated to 73 – 75deg for homogenisation at 140 – 200 bar, the mix is pasteurised at 83 – 85deg for about 15 seconds then cooled down to 5deg and transferred to an ageing tank.

    -Ageing:
    The mix must be aged for at least 4 hours at a temperature between 2 to 5degc with continuous gentle agitation. Ageing allows time for the stabiliser to take effect and the fat to crystallise.

    -Continuous freezing:
    •to whip a controlled amount of air into the mix;
    •to freeze the water content in the mix to a large number of small ice crystals.

    -Filling in cups, cones and containers;
    -Extrusion of sticks and stickless products;
    -Moulding of bars
    -Wrapping and packaging
    -Hardening and cold storage

    Equipment list and technical parementers FOR 1000L/H ICE CREAM PRODUCTION LINE

    NO.FLOW NO.NAMESIZEMAIN TECHNOLOGY PARAMETERUNIT
    1ABLENDING UNIT
    2A-1Blending tank1000LSUS304 stainless steel, heat insulated, bottom high speed emulsifier, digital readout thermometer, supporters with adjustable feetSet
    3A-2Milk pump5T/HSUS304 stainless steel, pump lift is 24 meters, mechanical sealSet
    4A-3Mini set of plate-type heat exchanger5T/HSUS304 stainless steel, two stages, △T1=50°C, △T1=30°C, temperature automatic controlSet
    5A-4Twin piping filter5T/HSUS304 stainless steel, two pipe, stainless steal filter element 100 meshSet
    6A-5operation platform SUS304 stainless steel, water drainage in central, handrail and staircase, dimension is 3000*1200*1100mmSet
    7 Subtotal
    8CHOMOGENIZER/PASTEURIZE UNIT
    9C-1plate type pasteurizer1T/hSUS304 stainless steel, plate type, inlet temperature 4℃, pasteurizing temperature 95℃, holding tube 300S for milk ,outlet temperature 43℃, PID temperature auto control, steam heating ,Spirax Sarco steam control system,JUMO temperature sensor,milk balance tank, milk pump, plate heat exchanger, pipes and valves, frame and support, electrical control box etcpcs
    10C-2high pressure homogenizer1T/h25MPa,(starting box included)pcs
    11 subtotal
    12DICE CREAM AGING UNIT
    13D-1aging tank2000LSUS304 stainless steel, three layers, miller jacket ,PU heat insulated, top center frame agitator, conical head, airtight manhole, breather valve, digital readout thermometer, anti-eddy baffle, supporters with adjustable feetSet
    14D-2Rotor pump2T/HSUS304, Mechanical Seal,Set
    15 Subtotal
    16ECIP UNIT
    17E-1Semi-automatic CIP system3×1TThree tanks, single circulation, Semi-auto CIP, double layer insulation tank, tank material SUS304 stainless steel,acid&alkali tank with stirrer, high&Low liquid level alarm system, Spirax Sarco temperature auto control, JUMO temperature sensor, Shanghai YUAN brand progress pump 3 pieces, 10T/H, pumping lift 36M, ABB motor,100L concentrated acid & alkali tank which material is SUS316L , The USA imported pneumatic diaphragm pump two pieces.Set
    18RCIP return pump20T/HSUS316L stainless steel, pump lift is 24 meters, mechanical sealSet
    19 Subtotal
    20total equipment price
    21FINSTALLATON UNIT
    22F-1stainless piping systemincluding CIP systemand all product pipe line ,SMS standard,¢63,¢51,¢38set
    23F-2power piping systempower pipe line ,without heat insulationset
    24F-3electric controlling boxcontrol box of all equipments,customer connect the electic cable to the electric controlling box of Beyond companyset
    25F-4electric installation materialelectric installation material of all equipmentsset
    26F-5installation and commissioning costdomestic mounting and debugging of all machines offered by Beyond, buyer supply installatin tools and consumable itemsset


    Industrial 1000l Ice Cream Making Machine For Ice Cream Processing LineIndustrial 1000l Ice Cream Making Machine For Ice Cream Processing Line
