    SUS304 Carbonated Beverages Pasteurization Tunnel Stepless Speeding

    Ask Lasest Price
    Brand Name : Beyond
    Model Number : different model
    Certification : CE Certificate
    Payment Terms : L/C, T/T
    Supply Ability : 50 Set/Sets per Month
    Delivery Time : Shipped in 60 days after payment
    • Product Details
    • Company Profile

    SUS304 Carbonated Beverages Pasteurization Tunnel Stepless Speeding


    New design warm water to cool and spraying cold water to cool down pasteurization tunnel for sale


    designed specially for milk, juice, drink, beer, food and drug after ,packaged, which can help to postpone the storage period by sterilizing and cooling. It is recommended as a second pasteurization in the pipe lining. It can be prepared in different process even with high auto-controlling according to the specific request from customer like heating, sterilizing, warm-keeping and cooling.

    This equipment has been widely used by the craft brothers. It’s more equal, compensate and rapid than traditional water sterilization which can help to improve the efficiency and decrease the manufacturing cost and improve market competition for the customers. The main character of this equipment is that the net can be used for a long time, and won’t bring a large distortion in high temperature, which is used the imported spray mouth to homogenize the flow and temperature. The temperature can be chosen as the PLC or PID controlling.


    ModelPLS-3000PLS-6000PLS-8000PLS-12000PLS-18000
    maximum sterilize temperature100℃
    line speed of the conveyer

    110-553mm/min

    Stepless speeding

    heating steam pressure0.4MPa
    heating water consumption (M3 )21405580120
    Total power(kw)9.610.613.616.525
    External dimension(mm)length650014000188802188031000
    width22502750
    height17351735
    weight (kg)300050006500850012000
    Tunnel area (m²)13.526.5345176


    Quality SUS304 Carbonated Beverages Pasteurization Tunnel Stepless Speeding for sale
