    200TPD UHT Batch Pasteurizer Machine , Milk Pasteurization Unit

    Ask Lasest Price
    Brand Name : BEYOND
    Model Number : BY-UT
    Certification : ISO 9001/SGS/CE/TUV
    Price : 100000USD-800000USD/set
    Payment Terms : T/T, L/C, west union
    Supply Ability : 20 sets per month
    Delivery Time : 80-100days upon the recipt of downpayment and confirmation of drawings
    • Product Details
    • Company Profile

    200TPD UHT Batch Pasteurizer Machine , Milk Pasteurization Unit

    Pasteurized Milk Yogurt Milk Drinks Pasteurization machine UHT Milk Production Line/Mini Dairy Processing Plant Equipment

    We focus on the research and development of new technologies and have rich experience in pasteurized milk and UHT milk processing equipment such as milk receiving, cream separation, processing, milk standardization and liquid milk filling.
    We will always provide complete design and possibility according to the requirements of customers and the budget of milk processing equipment and dairy processing plant.


    Pasteurized milk is also called sterilized milk. It is made from qualified fresh milk. It is pure milk after centrifugation, standardization, homogenization, pasteurization, cooling and filling. It is directly supplied to consumers as commercial milk.
    In modern UHT plants, milk is pumped through a closed system. In this process, it will not be infected again after preheating, high temperature treatment, homogenization, cooling and aseptic packaging. Milk is usually treated at 135 – 150 ° C for a few seconds by indirect heating, direct steam injection or steam injection.


    Brief introuction of UHT dairy processing plant

    Brand Name:Shanghai Beyond
    Model Number:BY-UM
    Capacity5-200TPD
    Raw material

    Fresh cow milk, buffalo milk, goat milk, camel milk

    or milk powder, or both mixed

    End productPure milk, UHT milk, long shelf life milk
    Shelf life

    35-40days, 3months, 6months, 12months

    (keep at room temperature )

    Final product fat (%)

    Semi-skimmed or double toned milk (1.5%);

    Full cream(3% or 6%); Toned milk(3%)

    SNF8.5%(min)
    Main material for machinesSUS304 or SUS316
    Package for end productplastic pouch
    Certification:ISO9001/CE/SGS
    Place of Origin:China
    Manufacturer historyMore than 10years


    Features and advantages:

    1. Processing capacity can be ranged from 2T/Day to 1000T/Day.

    2. High standard design, manufacture and project installation requirements, which guarantee the first-class finish products in the dairy processing line.

    3. PLC control the whole production line, saving labor force and facilitate production management.

    4. Full-auto CIP cleaning, to ensure whole production line equipments meet food sanitary safety requirements.

    5. Whole line with features as high level automatic, low labour intensity, easy operation, safe function and low operation cost.

    6. Whole line adopt sanitary design, can be cleaned thoroughly, with high level sanitation.


    Equipment list and technical details:

    Flow No.NameSizeMain technology parameterUnitQTY
    AMilk collection and storage unit
    A-1chiling tankV=3000LSUS304 stainless steel,dimple pad jacket,attached with compressor, temperature automatic control, sealed manhole, breath valve, CIP spray ball, entire frame supportpcs2
    A-2milk transport tankV=5000LSUS304 stainless steel, PU insulation, devided to 2 chambers, saddel type legs, with two manholes, spray balls, product outlet etcpcs1
    A-3loadometer maximum weighing 15TPCS1
    A-4Milk pump10T/HSUS304 stainless steel, pump lift is 24 meters, mechanical sealSet1
    A-5Twin piping filter5T/HSUS304 stainless steel, two pipes, stainless steal filter element 100 meshSet1
    A-6Milk cooling tank3000L
    SUS304 stainless steel,dimple pad jacket,equipped with compressor,temperature automatic control,sealed manhole, breath valve, CIP spray ball, entire frame support
    Set2
    A-7Milk pump3T/HSUS304 stainless steel, pump lift is 24 meters, mechanical sealSet1
    A-8Milk pump10T/HSUS304 stainless steel, pump lift is 24 meters, mechanical sealSet1
    A-9powder and liquid mixer10T/hSUS304,horizontal typeset1
    Bpasteurizing unit
    B-1
    plate pasteurizer
    1T/HSUS304 stainless steel, plate type, product inlet temperature 5℃, cream separator temperature 55℃,homogenizer temperature 65℃, pasteurization temperature 72-95℃,15S,output temperature 5℃,semi-automatic controlSet1
    B-2High pressure homogenizer1T/H25MPa, including starting cabinetPCS1
    B-3buffer storage tank2000Lmaterial is SUS304,insulation,with decentration agitator,conical head,sealed manhole,breather vent,simple valve,digital show thermometer,plate anti vortex,adjustable legsPCS1
    B-4Milk pump3T/HSUS304 stainless steel, pump lift is 24 meters, mechanical sealSet1
    CSterilization & Filling unit
    C-1Tubular sterilizer1-1.25T/HSUS304 stainless steel, aseptic tye, tubular type, inlet temperature 5℃, sterilization parameters:137℃,4S,output temperature 10-20℃,PLC automatic controlSet1
    C-2Full-automatic
    vacuum degasser
    1-1.25T/HFull-automatic control, SUS304 stainless steel, differential pressure transducer imported from Germany Labom, working vacuum degree -0.64~-0.85Kpa, flow control is frequency converted type, working together with sterilizer, with condensing devicePCS1
    C-3High pressure homogenizer1-1.25T/H
    25MPa, including starting cabinet, frequency conversion control
    PCS1
    C-4Aseptic pouch filling machine one head,4500pcs/hour, 250ml/pcsPCS1
    C-5belt conveyor material SUS304, length 4mPCS1
    DCIP system
    D-1Semi-automatic CIP system3×0.8TSUS304 stainless steel, conjoined structure with single cleaning way, concentrated acid/alkali tank adding system based on US technology, temperature automatic control, 50L×2 acid/alkali concentrate tanksSet1
    D-RCIP return pump20T/HSUS316L stainless steel, pump lift is 24 meters, mechanical sealSet3
    EACCESSORY EQUIPMENTS
    E-1chiller air-cooled compressor,with F22 as chilling medium, 20000Kcal, with ice water tank and ice water pumppcs1
    E-2steam boilerQ=500Kg/hcoal-burning type, steam pressure 8bar, with water treatment and dust removerpcs1
    E-3air compressorQ=1m3/minscrew type air compressor, include air storage tank, cold drier unit etcpcs1
    E-4RO water treatment system2T/hincluding sand filter, carbon filter, ion exchange,one stage RO system, automatic controlSET1
    E-5water tank5000LSUS304, single layerSET2
    FInstallation part
    F-1Stainless steel piping system Including CIP system and all product pipe line of whole preparation unit up to filling part, SMS standard, ¢63, ¢51, ¢38Set1
    F-2Power piping system Power pipe line of whole preparation stage till filling part, not include heat insulationSet1
    F-3Electric controling box
    Control all equipments of whole preparation stage up to filling part
    Set1
    F-4Electric installation material Electric installation material of all equipments of whole preparation stage up stoped at filling partSet1
    F-5Mounting and debugging fee
    Domestic mounting and debugging of all machines offered by Beyond (if out of China, the buyer should pay the round-air ticket fee and road cost , the food and hotel fee person per day for subsidy)
    Set1

    Factory preparation requirement for 1500LPH UHT Dairy Processing Plant from Milk Powder Or Fresh Milk

    Product Name5-200TPD Long shelf life UHT milk line
    Processing line typeComplete turn-key project
    Power consumption(Kw)energy saving type, about 100-500kw,
    Operator neededAbout 4-18persons
    Cooling water consumptionAbout 60-500M3
    Steam consumptionAbout 200-4000T/H,
    Factory space neededAbout 400-6000Sqm
    Warranty12 months

    200TPD UHT Batch Pasteurizer Machine , Milk Pasteurization Unit200TPD UHT Batch Pasteurizer Machine , Milk Pasteurization Unit


    Our service

    The seller will provide technical training to the buyer. The training contents include: equipment structure and maintenance, control and operation. After training, the buyer's technicians will master relevant operation and maintenance skills, be more skilled in adjusting technology, and be able to deal with various faults in time.


    after-sale service

    1) After the equipment is qualified, the seller will provide one-year warranty, one-year warranty of control system, free wearing parts and other spare parts at the cost price. During the warranty period, the trained technicians shall strictly comply with the equipment operation and maintenance requirements required by the seller, find and eliminate common faults in time; If the buyer's technicians cannot solve the problem by themselves, the after-sales department will provide remote guidance service by telephone; If relevant measures cannot solve the problem, the seller will send technicians to the buyer's factory to eliminate faults or relevant technical problems on site. The cost will refer to the installation and commissioning cost.


    2) After receiving the guarantee, the seller will provide extensive preferential technical support and lifelong after-sales service: preferential prices for vulnerable parts and other spare parts.
