    220V / 380V Voltage Fruit Processing Machine 2 - 10kw Power Hammer Type Crusher

    Ask Lasest Price
    Brand Name : Beyond
    Model Number : 2TPH-20TPH
    Certification : ISO9001
    Price : $15,000.00 / Piece
    Payment Terms : L/C, T/T
    Delivery Time : 30 work days
    • Product Details
    • Company Profile

    220V / 380V Voltage Fruit Processing Machine 2 - 10kw Power Hammer Type Crusher


    Hammer typer crusher for pulping fruits and vegetables



    • Equipment Characteristics

    This machine is composed of side cover,swift knife,screen,main body,principal axis etc.the principal axis is regularly driven to circumvolve by a couple straps on running wheels; so the knives on the principal axis with circumvolve swiftly. When the fruits drop down to the feeding hopper from the lifer, they will be crushed by the swift knives; the crushed fruits will fly through the filter net on the drum to the storage groove under the centrifugal effect.

    • Scope of application

    Widely applied in crushing the fruit and the vegetables

    • Equipment Advantages
    The crushed materials are of the nearly same granularity,and its size is determined by the screen mesh of waist hole.

    .• Techinical parameters

    (1)Model type:Hammer piece type crusher

    NameDescriptiopnProcessing Capacity(L*W*H)
    External dimension(mm)
    Suggested power
    (KW)
    CPPSJ-2All materias made of stainless steel SUS304capacity:≤2(T/H)995*510*5653
    CPPSJ-5capacity:3~5(T/H)1100*580*6455.5
    CPPSJ-10capacity:6~10(T/H)1300*750*6457.5

    (2)Model type:Hammer type crusher

    NameDescriptionProcessing CapacitySuggested Power(KW)
    CPSJ-5All materias made of stainless steel SUS304≤5(T/H)15
    CPSJ-1010(T/H)18.5
    CPSJ-2020(T/H)22
